A bubbler head is installed within the plant basin at the top of the mulch layer, connected by a one-half-inch diameter Schedule 80 PVC nipple of required length. The riser connects through a swing joint assembly made of one-half-inch diameter Schedule 80 PVC to the lateral irrigation line. One bubbler is provided per tree, positioned above the finish grade.
LATERAL LINE SWING JOINT ASSEMBLY 1/2" DIA. SCHEDULE 80 PVC PVC SCHEDULE 80 NIPPLE 1/2" DIAMETER (LENGTH AS REQUIRED) BUBBLER HEAD (INSTALL WITHIN PLANT BASIN) TOP OF MULCH NOTE: 1. ONE BUBBLER PER TREE FINISH GRADE 3"
