A stainless steel drain cover sits atop a drain body recessed flush with the surrounding planting soil. The planting layer and soil depth are sized per the planting and soils plans. The drain outlet connects to underlying piping sized and routed per the civil drawings.
STAINLESS STEEL DRAIN COVER PLANTING, SEE PLANTING PLAN DRAIN BODY PLANTING SOIL, SEE SOILS PLAN FOR CONNECTION, SEE CIVIL DWGS. REF: L9-401 1 1/2" = 1'-0" 8 PLANTING AREA DRAIN, TYP.
