L-NMY4M — Typ Interior Non-Bearing Stud To Wx Beam Conn

Landscape · L-NMY4M

Typ Interior Non-Bearing Stud To Wx Beam Conn

Units: imperial
Sheet: LO-S1.4.2
Discipline: Landscape

Materials

Cold-formed Steel Concrete Metal (misc.)Steel Timber / Wood

Elements

Anchors / Embeds Beams Decks Partitions

Connections

Deck Attachment Expansion / Slip Connection

Text on the drawing

SLIP TRACK PER 3 SIDES STUD WEB TO BOTTOM FLUTE, TYP 400S162-54 STUD @ 4'-0" OC STAGGERED EACH SIDE OF Wx BEAM, SEE NOTE BELOW 1 1 METAL STUDS METAL DECK (W/ OR W/O CONC FILL) PER PLAN CONNECT TO BEAM FLANGE W/ (2) HILTI 0.157"Ø X-U PAF @ 48" OC 1/2" MIN 1" LAP 1/8 / 9 LO S1.4.5 LO S1.4.4 12
