An irrigation trench profile details the burial depth and separation requirements for PVC mainline and lateral pipes. A two-inch layer of sand or rock-free soil surrounds all pipe bedding. Control wires tape to the side of the PVC mainline at ten-foot intervals on center. The trench includes a six-inch vertical spacing between the mainline and lateral line, with a two-inch horizontal separation. Compacted backfill fills the intermediate trench depth up to a five-inch deep layer of topsoil beneath the finish grade in lawn areas.
PVC LATERAL LINE (18" DEEP FOR ROTOR AND IMPACT HEAD INSTALLATIONS) COMPACTED BACKFILL FINISH GRADE 5" DEEP TOPSOIL IN LAWN AREAS 2" SAND OR ROCK FREE SOIL AROUND ALL PIPE PVC MAINLINE TAPE WIRES TO SIDE OF MAIN LINE AT 10'-0" O.C. 12" 6" 2" HORIZONTAL SEPARATION
