The drawing illustrates a cross-section of a 7-inch concrete element with internal reinforcing or embedded components. It includes a 1-inch conduit (1"C) and a slotted or ribbed profile embedded directly within the concrete matrix, along with two smaller circular voids or inserts near the top corners. Dimension lines indicate a 7-inch width for the overall assembly.
Text on the drawing
1"C 7" EXISTING SECTION E
