A 12 to 18-inch plexi or glass windscreen rests above a slab bar top supported by a panel system from Bok Modern. The vertical assembly is anchored with a knife blade bracket specified as type A, B, C, or D, secured via half-inch stainless steel bolt assemblies. The entire railing and windscreen assembly terminates at a non-mounted base plate resting on the top of the hardscape surface for a flexible configuration.
