L-MBB6V — Controlled Environmental Room Panel Detail

Landscape · L-MBB6V

Controlled Environmental Room Panel Detail

Units: imperial
Sheet: LO-LF4.1.11
Discipline: Landscape

Materials

Stainless Steel Steel

Elements

Connections / Plates Insulation Partitions Walls

Text on the drawing

PARTITION WALL (REFER TO ARCHITECTURAL DOCUMENTS) STAINLESS STEEL SCREWS 18 GAUGE STAINLESS STEEL CLOSURE ANGLE SEALANT (3/8" TYPICAL) INSIDE INSULATED PANEL PLAN
