A stainless steel pipe bike rack is embedded into a reinforced cast-in-place concrete footing and paving assembly. The rack is fabricated from 5/16-inch thick stainless steel pipe with a number 4 brush finish. The concrete footing incorporates number 4 top and bottom longitudinal reinforcing bars with hooks at the ends, along with number 4 stirrups spaced at 12 inches on center. Two-inch concrete cover is provided typically unless noted otherwise.
2'-7 1/4" 3'-0" 5/16" SS PIPE #4 BRUSH FINISH 5/16" SS PIPE 1' - 0" 1' - 0" 1' - 0" 9" CONCRETE PAVING 2' - 9" 1' - 10 1/4" 2" 3" 2" CVR TYP UNO (2) #4 T&B; HOOK AT ENDS #4 @ 12" STIRR @12"
