An epoxy resin sink is set into the countertop opening and secured with epoxy resin adhesive at the flanged joint. An epoxy resin overflow, sink stopper, and outlet piece connect through the bottom drain opening, with insulated pipe covers provided typically on the drain piping below. Sizing and dimensions are determined per the sink schedule.
EPOXY RESIN SINK (REFER TO SINK SCHEDULE FOR SINK DIMENSIONS) EPOXY RESIN ADHESIVE EPOXY RESIN OVERFLOW, SINK STOPPER AND OUTLET PIECE BY DIV. 11 SECTION APPROACH SIDE INSULATED PIPE COVER TYP. 5"
