A concrete slab features a surface-tooled control joint to regulate cracking, supported over a compacted aggregate base and subgrade. A welded wire reinforcement mesh is embedded within the mid-depth of the concrete pour.
A. TOOL JOINT 1 6 3 4 4 1 5 7 7 2
