The tree is placed in a planting pit twice the size of the root ball, with the trunk flare positioned one inch above the finished grade. The root ball is prepared by removing the wire basket and burlap from the top and sides, and the root collar is exposed for inspection. The pit is backfilled with a soil mix in six-inch layers, which are lightly compacted and watered thoroughly without tamping, while the sides of the pit are scarified. A three-inch layer of mulch is applied at the surface. The tree is secured with at least two stakes driven outside the root ball to half the height of the tree, using rubber tree chain for attachment.
Text on the drawing
REMOVE EXCESS SOIL AT ROOT COLLAR OF TREE. EXPOSE ROOT COLLAR FOR INSPECTION BY L.A. 3" OF MULCH 1" RUBBER TREE CHAIN BACKFILL WITH SOIL MIX, WATER IN 6" LAYERS DO NOT TAMP SCARIFY SIDES OF PLANTING PIT REMOVE WIRE BASKET & BURLAP FROM TOP AND SIDES OF ROOTBALL LIGHTLY COMPACTED SOIL MIX, WATER THOROUGHLY NOTES: 1. DRIVE STAKES OUTSIDE OF ROOT BALL - SINGLE STAKE TREES LESS THAN 6'. 2. PLACE TREE WITH TRUNK FLARE 1" ABOVE FINISHED GRADE. 3. REFER TO SPECS FOR ADDITIONAL INFORMATION. 2X SIZE OF ROOTBALL TREE STAKES - MIN. 2 PER TREE 1/2 HEIGHT OF TREE VARIES
