L-K6GK6 — Typical Duct-Bank Section (Traffic And Non-Traffic Area)

Landscape · L-K6GK6

Typical Duct-Bank Section (Traffic And Non-Traffic Area)

Units: imperial
Sheet: LO-E6.0.1
Discipline: Landscape

Elements

Foundations / Footings Site / Paving

Text on the drawing

32" (TYP) 24" MIN 48" MAX 2 1 1. WARNING TAPE. PLACE 12" ABOVE DUCT BANK. 2. SAND BACKFILL (NO ROCKS OVER 10" DIAMETER). 3. 6" OR 12" SAND SHADING AFTER COMPACTION. 4. ROADSIDE FINAL GRADE. 5. EXCAVATED DIRT PILE. 6. 36" MIN COVER. 7. 4" SAND BEDDING. 8. REFER TO CONDUIT BANK SECTIONS. NOTES: 3 9" 9" D 4 5 6 7 8 NON-TRAFFIC AREA NONE 1 TYPICAL DUCT-BANK SECTION (TRAFFIC AND NON-TRAFFIC AREA)

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
