L-K39B8 — Gridline L Step

Landscape · L-K39B8

Gridline L Step

Scale: 3/4" = 1'-0"
Units: imperial
Sheet: LO-S5.0.1
Discipline: Landscape

Materials

Concrete Metal (misc.)Steel Timber / Wood

Elements

Beams Connections / Plates Decks Floors / Slabs Roofs Walls

Connections

Deck Attachment

Text on the drawing

L WX BEAM PER PLAN METAL DECK W/ CONC FILL PER PLAN WX BEAM PER PLAN STUD WALL S.A.D. ROOF DECK PER PLAN LO S1.4.8 8 LOW ROOF VARIES LEVEL 2 STUD TO DECK CONNECTION PER / 1 LO S1.4.8
