L-JP6QP — Glulam Column To Steel Column

Landscape · L-JP6QP

Glulam Column To Steel Column

Units: imperial
Sheet: LO-S1.6.1
Discipline: Landscape

Materials

Concrete Metal (misc.)Steel Timber / Wood

Elements

Beams Columns Connections / Plates Decks Floors / Slabs

Connections

Bolted Connection Timber / Mass-Timber Connection Welded Connection

Text on the drawing

2" T.O. FLOOR GLULAM COLUMN PER PLAN WX COLUMN PER PLAN WX BEAM PER PLAN 3/4" STEEL PL. MATCH COL. SIZE OR 1/2" MIN. LARGER THAN STEEL COL. WHICHER IS LARGER A A STEEL PL METAL DECK W/ CONC FILL A-A VIEW GRID EQ EQ GRID C L C L 2" 3" 5 1/2" 1/2" KNIFE PL. 3/4" THRU BOLTS W/ WASHERS 6" 1/4 3/16
