An Irritrol Climate Logic weather sensor system features a wall-mounted controller connected to a receiver module. The controller interfaces with a power source and a conduit for control wiring. The receiver module is mounted near the controller with a connection cord plugged into the controller's remote port. Alternate mounting details show flat surface mounting using screws and gutter mounting using a QuickClip.
Irritrol CLIMATE LOGIC 69 F 40% 1:15a MENU No Rain-Irrigation 11/16 CL-M1 SMART RX ENABLED % WALL MOUNT CONTROLLER - REFER TO CONTROLLER DETAIL CONDUIT FOR CONTROL WIRE POWER SOURCE GUTTERMOUNT USING "QUICKCLIP" FLAT SURFACE MOUNT USING SCREWS RECEIVER MODULE MOUNTED NEAR THE CONTROLLER. CONNECTION CORD PLUGGED INTO CONTROLLERS REMOTE PORT
