Tree Planting Root Barrier and Staking Plan Detail

Elements

About this detail

Four three-inch diameter lodge pole pine stakes surround the tree root ball and connect via four corded rubber tree ties and one-by-four cross bracing. An irrigation bubbler sits directly on the root ball. Root barriers are installed on two sides per city standards with a minimum four-foot dimension as detailed on layout plans. An inspection tube is positioned near the adjacent curb, which coordinates with civil drawings alongside adjacent variable paving conditions.
