Plant centers are arranged in a triangular spacing pattern at the specified on-center distance. The distance from the edge of the planting area, paving, lawn, or equal is set to one-half of the specified on-center spacing.
TRIANGULAR SPACE, AT SPECIFIED O.C. DISTANCE - EQUIDISTANT EDGE OF PLANTING AREA; PAVING, LAWN OR EQUAL DISTANCE FROM EDGE IS 1/2 THE SPECIFIED O.C. SPACING PLANT CENTER . O.C. SPACING O.C. SPACING
