The steel bottom rail connects to the vertical post with a 1/4 inch fillet weld typical at the joint. A mechanical fastener secures the overlapping rail sections through a slotted hole configuration with a 1 inch spacing. Dimensions detail a 3 inch overall length with 1 1/2 inch spacing increments for the connection hardware.
6 3" 1 1/2" 1" 9 9 8 6 6 6 A 10 TYP. 1" 3" 1 1/2" 8 1/4" 6
