L-H5XXB — Recessed Walk Off Mat

Landscape · L-H5XXB

Recessed Walk Off Mat

Scale: 12" = 1'-0"
Units: imperial
Sheet: LO-A9.4.1
Discipline: Landscape

Materials

Elements

Entrances Floors / Slabs

Text on the drawing

3/4" 1/4" SERRATED ALUMINUM INSERT ALUMINUM LEVEL SQUARE END VINYL CONTINUOUS VINYL CUSHION PENDANT RAIL 2" 1" ALUMINUM LEVEL RECESSED WALK OFF MAT SLIP RESISTANT, CHEMICAL RESISTANT SEAMLESS RESINOUS FLOORING PER FINISH SCHEDULE
