The drawing breaks down the geometric components of a lag screw and its corresponding pilot hole. It details the unthreaded shank length, thread length excluding the tip, shank diameters, and the specific reduced-diameter predrilled hole profile required for proper timber installation. Callouts provide sizing rules, such as the predrilled pilot hole diameter being 40% to 70% of the unthreaded shank diameter.
Text on the drawing
DIAMETER OF UNTHREADED SHANK DIAMETER OF THREADED SHANK THREAD LENGTH (EXCLUDES TIP LENGTH) UNTHREADED SHANK LENGTH PREDRILLED HOLE PROFILE DIAMETER: 40% TO 70% OF UNTHREADED SHANK DIAMETER DIAMETER OF UNTHREADED SHANK LAG SCREW DIMENSIONS AND PREDRILLED HOLE PROFILE
