A one-quarter inch tooled control joint occurs within cast-in-place concrete paving. The joint features a one-quarter inch tooled radius edge and extends to a depth of one-quarter of the slab thickness typically. The overall slab thickness is determined per structural drawings, and the surface finish is sized per plan.
1C. SECTION - SAW CUT CONTROL JOINT 1E. SECTION - TOOLED CONTROL JOINT SLAB THICKNESS, SEE STRUCTURAL C.I.P. CONCRETE PAVING SEE PLAN FOR FINISH 1 4 " TOOLED JOINT (TOOLED 1 4 " RADIUS EDGE); DEPTH TO BE 1/4 SLAB THICKNESS, TYP.
