A precast concrete curb rests on a structural slab with a waterproofing system and rigid insulation. Concrete unit pavers are supported on a pedestal system adjacent to the curb, bedded in a six-inch mortar setting bed. A weephole is provided through the base of the curb assembly for drainage above the waterproofing layer.
6" MORTAR SETTING BED PRECAST CONCRETE CURB CONCRETE UNIT PAVER PEDESTAL SYSTEM WATERPROOFING SYSTEM SEE ARCHITECTURAL DRAWINGS STRUCTURAL SLAB SEE STRUCTURAL DRAWINGS WEEPHOLE RIGID INSULATION SEE ARCHITECTURAL DRAWINGS
