The drawing illustrates a rectangular element with circular voids and interlocking modular units embedded in a cast material, likely concrete. Dimension lines indicate spacing variables A, B, and overall formulas such as 2xA+(NxB) for layout control. Key callouts point to reinforcing elements and modular structural components.
Text on the drawing
A B B A 1 2 3 4 TYPICAL 2xA+(NxB) 2xA+(NxB) B B
