L-GQT78 — Conventional Casework - Island Bench

Landscape · L-GQT78

Conventional Casework - Island Bench

Units: imperial
Sheet: LO-LF4.1.9
Discipline: Landscape

Materials

Metal (misc.)Steel

Elements

Floors / Slabs Millwork / Casework

Text on the drawing

UNITSTRUT PIPE SUPPORT ASSEMBLY W/ TOP & BOTTOM @48" O.C. MAX. SECURE VERTICAL SUPPORT TO CABINET BACK TOP AND BOTTOM ALL SHELVES TO BE MAXIMUM DEPTH OF CABINETS U.O.N. UTILITY CHASE BENCHTOP, REFER TO FLOOR PLANS FOR TOP MATERIAL 60" U.N.O. 1" 22" 14" 22" 1" 3" 3" VARIES, SEE PLANS 4" PIPE SUPPORT ASSEMBLY LO LF4.1.9 3

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
