A standard fulcrum latch is mounted around a post and secured with a lever arm welded directly to the latch. The lever arm matches the width and height of the fulcrum latch post plate and is welded to match. Additional plates are welded adjacent to match the fulcrum latch assembly.
3" 1 STANDARD FULCRUM LATCH LEVER ARM WELDED TO FULCRUM LATCH. LEVER ARM TO BE SAME WIDTH AND HEIGHT AS FULCRUM LATCH POST PLATE WELDED TO MATCH FULCRUM LATCH 2 3 3 1 2 PLAN VIEW A --- 1 1/2" SECTION VIEW 'A' 3 2 1 4 4 1 1/2" 4 11 MODIFIED FULCRUM LATCH 1' = 1'-0"
