L-GNNX5 — Typical Canopy Rim Detail

Landscape · L-GNNX5

Typical Canopy Rim Detail

Units: metric
Sheet: LO-S5.0.1
Discipline: Landscape

Materials

Cold-formed Steel Steel Timber / Wood

Elements

Beams Canopies Ceilings Connections / Plates Roofs

Connections

Bolted Connection

Text on the drawing

5 CLOSURE PLATE T&B PER RIGID CLIP PER / 1 LO S1.4.8 SLIP-CRITICAL BOLTS LOW ROOF VARIES T.O. STUD TOP TRACK B.O. SOFFIT STUD LO S1.4.7 8 / 1 LO S1.4.8 FULL-HEIGHT WEB STIFFENER AT OPP. SIDE OF BEAM CONNECTION

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
