A vehicular double swing pipe gate spans between two vertical support posts set into cast-in-place concrete footings embedded in clayey silt soil. The gate assembly features horizontal and diagonal pipe members tied together with welded connections and mechanical fasteners, providing a secure access barrier. The hinge and latch posts extend to specified depths with variable span lengths determined per site plans. Drainage slopes are graded around the foundation bases to prevent water accumulation.
CLAYEY SILT S=200 L = VARIES, SEE PLANS SECTION 36" 36" 216" b=DEPTH D=DIAMETER 48" B=DIAMETER 6'-6" MAX 36" 216" SLOPE TO DRAIN SLOPE TO DRAIN 14 15 90" ℄ ℄ 16 2 2 2 1 2 4 3 ℄ d=DEPTH B1 E D GATE IN LOCKED OPEN POSITION
