A perimeter of rock sacks or sandbags placed along the edge of pavement directs flow for storm drain inlet protection. Inlets on grade require a one-bag high spillway, while inlets in sumps require a two-bag high configuration. Each inlet must be equipped with an internal filter fabric or basket. This assembly is for short-term use to inhibit non-storm water flow and must be removed upon completion of adjacent construction operations. These measures are not applicable in areas with high silts and clays unless used in conjunction with filter fabric.
Text on the drawing
MULCH, REF SPECIFICATIONS SOIL MIX: PLANTING SOIL FOR GARDENS OR LAWN MIX, SEE SPECS. INSTALL IN 4-6" LIFTS, TYP. SCARIFY SUBGRADE TO MIN. 4'-0" O.C. MIN. NOTES: 1. PROTECTED BY FENCING. WHERE CONSTRUCTION FENCING COINCIDES WITH TREE PROTECTION FENCING, TREES WILL BE PROTECTED BY CONSTRUCTION FENCE. 2. DISTURBED AREA, AS SHOWN ON PLANS, PRIOR TO COMMENCEMENT OF CONSTRUCTION. 3. THE BOUNDARIES OF THE TREE PROTECTION FENCING. 4. DURATION OF THE PROJECT. DRIP LINE FENCE MATERIAL YELLOW , UV RESISTANT, WIRE BACKED SILT FENCE TREE PROTECTION ZONE 2'-0" EDGE OF DISTURBANCE FINISH GRADE 4'-0" MIN.
