L-GH3MV — Glulam Beam To Glulam Girder With Beam Hanger

Landscape · L-GH3MV

Glulam Beam To Glulam Girder With Beam Hanger

Units: metric
Sheet: LO-S1.6.1
Discipline: Landscape

Materials

Elements

Beams Connections / Plates Roofs

Connections

Beam-to-Beam Timber / Mass-Timber Connection

Text on the drawing

ROOF GLULAM GIRDER PER PLAN GLULAM BEAM PER PLAN CLT PANEL, ORIENTATION MAY VARY CLT PANEL WHERE OCCURS SIMPSON HANGER PER PLAN GLULAM BEAM WHERE OCCURS CLT ATTACHMENT TO GLULAM BEAM PER / 8 LO S1.6.1 2 NTS 5

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
