Cast-in-place concrete paving features a wire basket with a speed dowel aligned beneath a one-eighth-inch sawcut control joint. The sawcut joint depth is typically one-quarter of the overall slab thickness. Slab thickness and concrete finish are determined per structural plans and specifications.
1B. SECTION - DOWEL BASKET JOINT SLAB THICKNESS, SEE STRUCTURAL C.I.P. CONCRETE PAVING SEE PLAN FOR FINISH 1/8" SAWCUT JOINT DEPTH TO BE 1/4 SLAB THICKNESS, TYP. WIRE BASKET WITH SPEED DOWEL
