L-GGHAG — 3. Angles Shall Be Placed On Top Of Deck.

Landscape · L-GGHAG

3. Angles Shall Be Placed On Top Of Deck.

Units: imperial
Sheet: L2
Discipline: Landscape

Materials

Steel Glass / Glazing

Elements

Beams Decks Roof / Floor Openings

Text on the drawing

TYPICAL L1 3/4x1 3/4x1/4 WEBS OF DECK BEAM BELOW EXTEND ANGLE 3 WEBS PASSED OPENING THIS IS CONSIDERED A SINGLE OPENING "B" "A" D2 D1 1/8 1/2 TYP ADJACENT TO CUT WEB

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
