The granite curb rests upon a compacted aggregate base, which is supported by a compacted subgrade. An expansion joint is detailed at the vertical interface between the granite curb and the adjacent bollard. The aggregate base depth is coordinated per civil drawings.
1 L9.03 Compacted Aggregate Base, See Civil Drawings Compacted Subgrade Expansion Joint 3b L9.01 Granite Curb Section Typ.
