L-FFADA — Adjustable Island Shelves (3-Tier) - Axonometric

Landscape · L-FFADA

Adjustable Island Shelves (3-Tier) - Axonometric

Units: imperial
Sheet: LO-LF4.1.4
Discipline: Landscape

Materials

Metal (misc.)Steel

Elements

Connections / Plates Floors / Slabs Millwork / Casework

Connections

Welded Connection

Text on the drawing

3'-0" (MAX. SPACING) ISOMETRIC VARIES (REFER TO FLOOR PLANS) CAPPED ENDS VERTICAL FRAME MEMBER, PUNCHED 30" FROM TOP SAFETY EDGE AT FRONT AND REAR, REFER TO: MOUNTING ANGLES TO BE SECURED TO STRUCTURE ALL WELDS TO BE GROUND SMOOTH AND FREE OF BURS 2'-6" SHELVES ON OPPOSITE SIDE REMOVED FOR CLARITY ADDITIONAL SHELVES REMOVED FOR CLARITY 4 LO LF4.1.4 LO LF4.1.4 1

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
