Three guy wire assemblies secure the tree using a G2 guy fixing system equipped with tensioner shrouds and S61 anchors attached to ratchet tensioners. Three guy wire deadmen are positioned per tree, placed a minimum of ten inches from the edge of the rootball. All trees must be re-tensioned after planting due to settlement.
G2 GUY FIXING SYSTEM 3X TENSIONER SHROUDS 3X S61 ANCHORS ATTACHED TO RATCHET TENSIONERS 3X COLLAR, CLIP AND WIRE ASSEMBLIES 8M (26 FT) GUY WIRE DEADMEN (3) PER TREE PLACE MIN OF 10" FROM EDGE OF ROOTBALL NOTE: 1. DUE TO SETTLEMENT ALL TREES SHOULD BE RE-TENSIONED AFTER PLANTNG
