A jumbo valve box set at finish grade houses the drip zone control equipment. A main line pipe connects to a pressure regulator, a six outlet manifold, and PVC slip unions. Distribution tubing and bubbler stakes deliver water to planting areas. Brick supports and washed gravel provide a stable base within the valve box.
