Landscape · L-EHJQZ

Complete Joint Penetration Groove Weld

Units: metric
Sheet: LO-S1.1.1
Discipline: Landscape

Materials

Metal (misc.)Steel

Elements

Connections / Plates Roof / Floor Openings

Connections

Welded Connection

Text on the drawing

45.00° 1/4 CHIP, GRIND OR GOUGE TO SOUND METAL BEFORE FILLET WELDING
