L-EA4VA — Interior Wall Penetration Detail

Landscape · L-EA4VA

Interior Wall Penetration Detail

Units: metric
Sheet: LO-M5.0.2
Discipline: Landscape

Elements

Floors / Slabs Partitions Roof / Floor Openings Walls

Text on the drawing

PIPE PIPE SLEEVE 1 2 1. PROVIDE FIRESTOPPING / SEAL PER SPECIFICATIONS. TYPICAL FOR RATED WALLS. 2. ESCUTCHEON, FOR FINISHED INTERIOR WALLS. NOTES: (TYP)
