L-E74AT — Footing With Pilaster

Landscape · L-E74AT

Footing With Pilaster

Scale: 3/4" = 1'-0"
Units: imperial
Sheet: LO-S1.8.1
Discipline: Landscape

Materials

Concrete Reinforced Concrete Timber / Wood

Elements

Columns Floors / Slabs Foundations / Footings Reinforcing Walls

Text on the drawing

8.3 PILASTER FOOTING FOOTING THK PER PLAN FOOTING WIDTH FOOTING PILASTER WIDTH PER PLAN FOOTING LONG. REINF PER FTG SCHD FOOTING TRANSV REINF PER FTG SCHD T.O.FTG -2'-0" T.O.SLAB 0'-0" WX COL BEYOND PER PLAN STUD WALL S.A.D.
