A ten-inch round valve box sits flush with finish grade in lawn or shrub areas, supported by two bricks total and four inches of pea gravel below with no soil inside the box. A one-half-inch PVC ball valve connects to a four-foot coil of one-half-inch IPS Salco algae-resistant flexible PVC pipe. The flexible pipe transitions to a PVC Schedule 40 elbow socket by socket, connecting down to a rigid PVC lateral line buried twelve inches below grade.
10" ROUND VALVE BOX 1/2" PVC BALL VALVE PEA GRAVEL 4" DEEP (NO SOIL IN BOX) PVC SCHEDULE 40 ELL S X S FINISH GRADE STANT FLEXIBLE PVC. 4' COIL OF 1/2" IPS SALCO ALGAE RESI- BRICK-2 TOTAL LATERAL LINE PVC RIGID 0" IN LAWN GROUNDCOVER 1" IN SHRUB OR AREA 12"
