A three-quarter-inch diameter steel rod slides through seven-eighth-inch pipe sleeves welded to the steel gate frame and post. The assembly includes precise horizontal dimensions with a ten-inch clear opening span between members. Pipe sleeves are welded continuously along the full length of the pipe rod for structural stability. The slide bolt mechanism interfaces directly with the structural steel gate frame and supporting post elements.
7/8" PIPE SLEEVES- WELD TO GATE FRAME AND FOR FULL LENGTH OF PIPE STEEL GATE FRAME OR POST 3/4" DIA. ROD 4" 1" 2" 5" 4" 6 1/2" 6 1/2" 10" CLR. 1 2 3 1 3/4" DIA. ROD 2 PIPE SLEEVES - WELD TO GATE FRAME AND FOR FULL LENGTH OF PIPE ROD 3 STEEL GATE FRAME OR POST 4 4 STEEL GATE FRAME STEEL GATE FRAME
