A two-inch square stainless steel tube with a number four satin finish serves as the bicycle rack, anchored into a recessed cast-in-place concrete footing. Dimensions of four feet two and seven-eighths inches by two feet four and seven-eighths inches locate the bike rack assembly and footing relative to adjacent site elements.
2' - 4 7/8" 4' - 2 7/8" RECESSED CONCRETE FOOTING 2" SQ STAINLESS STEEL TUBE #4 SATIN FINISH
