Side elevation and end elevation views detail a pedestrian path curb adjacent to a wall, showing defined vertical and horizontal dimensions of one inch, two inches, and three-quarters of an inch. Equal spacing is measured from the centerline to the pedestrian path side and the side adjacent to the wall. The configuration indicates specific edge clearances and profile transitions for the curb assembly.
1" 2" 3/4" 3/4" CL EQ. EQ. 2 1 2 3 PEDESTRIAN PATH SIDE SIDE ADJACENT TO WALL 4 END ELEVATION SIDE ELEVATION 5
