Planting beds are laid out with a continuous outer row at a specified distance on center, set back from the edge of the planting bed or pavement by two-thirds of the recommended spacing or eight inches minimum, whichever is greater. Interior plants are arranged in a triangular spacing pattern throughout the bed, leaving an interior area designated for spacing adjustments.
X X X CONTINUOUS OUTER ROW AT X FEET ON CENTER. 2/3X FEET SETBACK FROM EDGE OF PLANTING BED WITH TRIANGULAR SPACING INSIDE BED (TYP) EDGE OF PLANTING BED OR PAVEMENT 2/3X OR 8" MIN. WHICHEVER IS GREATER (TYP) AREA FOR SPACING ADJUSTMENT X = RECOMMENDED SPACING (SEE LANDSCAPE DETAIL ON DRAWING) = ACTUAL PLANT LOCATIONS
