Finish grade is set one inch below the bollard beyond the tree per planting plan references. Metal framing indicates design intent requiring engineering and anchoring submittal drawings to be signed and sealed by a licensed professional engineer.
Finish Grade, Set 1" Below Bollard Beyond Tree, See Planting Plan 2 L9.06 NOTE: Metal Framing Indicates Design Intent. Engineering and Anchoring Submittal Drawings Shall be Signed and Sealed by a Licensed PE.
