Landscape · L-CF9GX

Partial Floor Plan 2A28

Units: imperial
Sheet: L2
Discipline: Landscape

Elements

Floors / Slabs Roof / Floor Openings

Text on the drawing

1S2 1' - 0" 1' - 0" 7' - 7" 7' - 10" FL. OPNG. 4' - 10" 1' - 10" 10' - 1" FL. OPNG. 4' - 10" 7' - 6" 6" 9' - 0" 6' - 9" R2
