The wall panel sits on an existing floor over a three-quarter-inch leveling sand bed and is anchored by one-quarter-inch diameter by four-inch long Tapcon anchors embedded two and a half inches minimum at twenty-three inch centers. A floor panel meets the wall panel with an NSF-approved radius at the interior corner. The exterior base of the wall panel is supported by two inches of mandatory backfill provided by others. The floor panel has a thickness of three and three-quarter inches while the adjacent exterior grade fill extends four and a half inches.
SECTION L - L 3 3 4 " 4 1 2 " 2 1 2 " MIN. FLOOR PANEL NSF APPROVED RADIUS WALL PANEL EXISTING FLOOR 2" MANDATORY BACKFILL REQUIRED (BY OTHERS) 3/4" LEVELING SAND (BY OTHERS) 1/4" x 4" LONG TAPCON ∅ ANCHOR EMBEDDED 2 1/2" MINIMUM AND LOCATED AT 23" CENTERS
