Tree planting on an existing slope within a plant pit featuring angled sides and a width equal to two times the root ball. The root ball rests on undisturbed soil and is surrounded by amended backfill. A water retention berm is formed downslope, and mulch is held back three inches from the base of the trunk. A two-to-one transition slope blends the excavated pit into the existing grade.
PLANT PIT WITH ANGLED SIDES AMENDED BACKFILL EXISTING SLOPE ROOT BALL WATER RETENTION BERM MULCH HOLD BACK 3" FROM BASE OF TRUNK UNDISTURBED SOIL 2:1 TRANSITION SLOPE 2X ROOTBALL
