L-BNR8E — Trench Detail (Four Conduits)

Landscape · L-BNR8E

Trench Detail (Four Conduits)

Units: imperial
Sheet: LO-T2.0.9
Discipline: Landscape

Materials

Elements

Site / Paving Walls

Text on the drawing

FINISHED GRADE. PATCH AND REPAIR TO MATCH EXISTING CONDITIONS 6" WIDE METALLIC WARNING TAPE PROPERLY COMPACTED SOIL CLEAN SAND BACKFILL 30" 3" 3" TYP. 12" MIN 3" C S TRENCH WALL 3" TYP. F S REFER TO DETAIL 3 FOR INNERDUCT WITHIN FIBER CONDUIT
