Cast-in-place concrete flatwork details on structure include sawcut joints, expansion joints, and transitions at vertical surfaces. A sawcut joint features a one-eighth-inch by one-and-one-half-inch deep cut above reinforcement and a backing wire. An expansion joint separates pour one and pour two with one-quarter-inch expansion material extending through the concrete slab. A concrete flatwork condition at a vertical surface incorporates expansion material and joint sealant with a maximum two percent slope. Reinforcing steel and welded wire fabric are placed within the structural concrete pour.
1/8" X 1-1/2" 1/4" EXPANSION MTL. POUR 2 POUR 1 DEEP 3 2 1 1 7 1 7 3 4 2 5 2% MAX. B. EXPANSION JOINT - ON STRUCTURE A. SAWCUT JOINT - ON STRUCTURE 6 3 6 C. CONCRETE FLATWORK AT VERTICAL SURFACE - ON STRUCTURE 6 8 8 8
