This assembly is supported by a structural concrete slab carrying insulation and waterproofing layers beneath a concrete topping slab. Stone boulders are embedded in a one-half-inch mortar setting bed with saw-cut bottom surfaces atop the topping slab. A three-inch perforated PVC pipe runs within a bed of one-to-two-inch river rock for drainage. Dimensions vary as specified per the plan.
Structural Slab, S.S.D. Insulation & Waterproofing, S.A.D. 3" PVC Perforated Pipe, S.P.D. Stone Boulders, 1 2 " Mortar Setting Bed -Saw Cut Bottom Surface 1-2" River Rock Topping Slab, S.A.D. Varies See Plan 2% ar Set in Concrete Topping Slab
